Deltabar PMD75B - differential pressure transmitter

Smart pressure transmitter which detects process anomalies like plugged impulse lines

PMD75B

Primerjava

Lastnosti na dlani

Accuracy

Standard:
up to 0.05 %
Platinum:
up to 0.035 %
Max. measurement error

Standard:
up to 0.05 %
Platinum:
up to 0.035 %
Measuring range

10 mbar...250 bar
(0.15 psi...3750 psi)
Process temperature

-40°C...+110°C
(-40°F...+230°F)
Pressure measuring range

10 mbar...250 bar
(0.15 psi...3750 psi)
Main wetted parts

316L, AlloyC,
Tantal, Monel,
Gold
Max. process pressure

420 bar (6300 psi)
Material process membrane

316L, AlloyC,
Tantal,
Monel,
Gold
Wetted materials

316L,
AlloyC,
Tantal,
Monel,
Gold
Measuring cell

10 mbar...250 bar
(0.15 psi...3750 psi)

Vse specifikacije

Področje uporabe

This transmitter belongs to the new Deltabar generation. The device is robust and can be remotely controlled via SmartBlue App using a secure Bluetooth connection. It allows condition based maintenance to increase plant availability.
The software is designed to simplify the handling. Intuitive wizards guide the user through setup, proof tests and verification of the device.
Heartbeat Technology offers verification and monitoring functions to detect unwanted anomalies e.g. plugged impulse lines.

Pressure measuring ranges up to 250 bar (3750 psi) (gauge/absolute) and 40 bar (600psi) (dp)
Static pressure up to 420bar (6300psi)
Accuracy: up to +/- 0.035%

Prednosti

With Heartbeat Technology you are able to verify the health of the device while the process is running. This increases plant availability.
Simple indication of device status - display changes from green to red when diagnostic messages occur
Reduce systematic failures - error free SIL commissioning and instrument guided proof testing
Control the device wireless in hard to reach process areas with the SmartBlue App
